8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803
8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803
8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803
8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803
8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803

8-port RS232/RS422/RS485 to TCP/IP serial server OX-5803

? Adopting a 32-bit 200MHz high-performance processor with low power consumption and stable product operation ? Supporting Windows real COM serial port driver program, providing complete serial port data for user applications ? Can be managed and configured through Web/Telnet/Console, with a fully Chinese interface and simple operation ? Supports universal Socket operation modes, including TCP Server/Clint and UDP modes ? Can connect two equivalent serial devices through the network without adding a computer ? 10/100M adaptive Ethernet interface, can manually set the working mode ? Network port signal built-in 15 KV ESD protection ? Serial port signal built-in 15 KV ESD protection, 600W surge protection ? Supports simple network management protocol SNMP MIB-II ? Supports standard Syslog protocol ? Supports standard Modbus RTU to Modbus TCP ? Supports RFC2217 Telnet terminal protocol ? Supports multi connection control (up to 8 devices) PC simultaneous control) ? Can be managed and configured through Web/Telnet/Console, easy to operate and maintain ? Has serial line detection function, timely discovers serial line connection status ? Has 1, 2, 4, 8, 16, 32 serial interfaces, making serial terminal devices easily networked

OX-5803 serial port server, also known as terminal server or serial communication server, is a converter between asynchronous serial port RS232/422/485 and Ethernet. It is an independent smart device with a CPU, embedded OS, and a complete TCP/IP protocol stack. Completing bidirectional transparent data transmission between RS232/422/485 and Ethernet enables RS232/422/485 serial devices to immediately connect to the network.



Number of serial ports

model

specifications

Serial port interface type

Power supply and appearance

notes

1opening

OX-5103E

1openingRS232/485/422changeTCP/IP

DB9terminal

9-40VDesktop power supply

OX-5103I

1openingRS232/485/422changeTCP/IP

DB9terminal

9-40VDesktop power supply

Industrial grade with isolated lightning protection, customizable1URack

2opening

OX-5201

2openingRS232changeTCP/IP

RJ45

5VDesktop power supply

9-40Vcustomizable

OX-5202

2openingRS485/422changeTCP/IP

RJ45

5VDesktop power supply

OX-5203I

2openingRS232perhapsRS485/422changeTCP/IP

terminal

5VDesktop power supply

Industrial grade with isolated lightning protection, customizable1URack

4opening

OX-5403

4openingRS232/485/422changeTCP/IP

RJ45

5VDesktop power supply

9-40Vcustomizable

OX-5403I

4openingRS232perhapsRS485/422changeTCP/IP

terminal

9-40VDesktop power supply

Industrial grade with isolated lightning protection, customizable1URack

8opening

OX-5803

8openingRS232/485/422changeTCP/IP

RJ45

5VDesktop power supply

9-40VCan be reserved

OX-5803I

8openingRS232perhapsRS485/422changeTCP/IP

terminal

9-40VDesktop power supply

Industrial grade with isolated lightning protection, customizable1URack

OX-5803D

8openingRS232/485/422changeTCP/IP

RJ45

220Vpower supply1URack

48VAnd interface type（DB9Or terminals) can be reserved

16opening

OX-5161

16openingRS232changeTCP/IP

RJ45

220Vpower supply1URack

OX-5162

16openingRS485/422changeTCP/IP

RJ45

220Vpower supply1URack

OX-5163

16openingRS232/485/422changeTCP/IP

RJ45

220Vpower supply1URack

32opening

OX-5321

32openingRS232changeTCP/IP

RJ45

220Vpower supply1URack

OX-5322

32openingRS485/422changeTCP/IP

RJ45

220Vpower supply1URack

OX-5323

32openingRS232/485/422changeTCP/IP

RJ45

220Vpower supply1URack
